Johnson Controls
PENN BY JOHNSON CONTROLS V48AF-2 VALVE
Price:
$1,200.00
Product details
Description
THREE WAY PRES ACT WATER; 1-1/4" 145/190# R-22
V48 Series valves are designed specifically for condensing units cooled either by atmospheric or forced draft cooling towers.V48 Series valves are used on single or multiple condenser hook-ups to the tower to provide the most economical and efficient use of the tower.
V48 Series valves are designed specifically for condensing units cooled either by atmospheric or forced draft cooling towers.V48 Series valves are used on single or multiple condenser hook-ups to the tower to provide the most economical and efficient use of the tower.
Specs
| Manufacturer Part Number | V48AF |
|---|---|
| Item Number | V48AF |
| Manufacturer | Johnson Controls |
| Product Series | V48 |
| Family Series | Johnson Controls HVAC Valves, V48 Series |
| Pipe Size | 1.25 Inches |
| Body Style | Three-Way |
| Min Opening Point | 145 |
| Max Opening Point | 190 |
| Application | Non-Corrosive Refrigerants |
| Inlet and Outlet | Threaded |
| Pressure Connection | Capillary with 1/4 in Flare |
