Copeland ZR45KC-TF5-235 Scroll Compressor

Technical specification :

• Capacity (BTU/HR): 48,200
• Type: Scroll
• Refrigerant: R-22
• Input Voltage (V):
  • 208
  • 230
• Number of Phases: 3
• Frequency (Hz): 60
• Rated Load Current (A): 17.1
• Max. Continuous Current (A): 24.0
• Locked Rotor Current (A): 114.0
• Crankcase Heater Included?: No
• Crankcase Heater Part Number: N/A
• Soundwrap (Brinmar): N/A
• Refrigerant Oil: POE ()
• Suction Line Location: 2
• Suction Line Height (in.): 11-3/16
• Suction Line Configuration: Stub Out
• Suction Line Size (in.): 7/8
• Discharge Line Location: 3
• Discharge Line Height (in.): 15-7/16
• Discharge Line Configuration: Stub Out
• Discharge Line Size (in.): 1/2
• Overall Compressor Height (in.): 16-7/16
• Mounting Base Dimensions (in. x in.): 7-1/2 x 7-1/2

These specifications provide detailed information about the compressor's capacity, electrical requirements, refrigerant type, and physical dimensions.
